Cooling temperature: -45℃ (at no load) (*)
Trapping volume: Approx. 500mL/time
Volume inside chamber: Approx. 4L (Inner dia. 160 x 205mm)
Compressor: 250 W
Recommended vacuum pump: Oil-sealed Rotary Vacuum pump (Ultimate pressure below 50 Pa, Displacement above 100 L/min)
Vacuum hose connection port: For outer dia. φ22 mm (Rc 3/8 Thread on inner surface, Convertible to different dia.), a hose with an inner diameter of φ18 mm is basically used.
Vacuum release: Leakage port with filter on the side of the body (N2 Gas purge combined use, Hose attachment port, Pisco φ6 mm), automatically released by halting the vacuum pump.
Other functions: Hot gas defrosting (thawing in approx. 30 minutes, outlet for the vacuum pump interlocking (Max. 3 sockets, 9 A, with operation switch)
Dimensions/Weight: 375 x 420 x 525 Hmm, Approx. 34kg
Power supply: AC100V/6A /Max.15A(Need a step-down transformer)
Standard accessories: Table mat × 1 pc
