Gain: 21.8 dB to 31 dB
VSWR: 1.92
Style: Panel
Width: 25 mm
Height: 4 mm
Length: 25 mm
Bandwidth: 10 MHz
IP Rating: IP67
Impedance: 50 Ohms
Cable Type: RG174
Technology: GPS L1 / Galileo E1
Application: Satellite Applications
Unit Weight: 70 g
Cable Length: 3 m
Polarization: RHCP
REACH - SVHC: Details
Mounting Style: Adhesive Mount
Number of Bands: 1 Band
Center Frequency: 1.57542 GHz
Mechanical Style: Module
Ground Plane Size: 25 mm x 25 mm x 4 mm
Maximum Frequency: 1.57842 GHz
Minimum Frequency: 1.57242 GHz
Termination Style: Connector
Antenna Connector Type: SMA Male
Protocol - GPS, GLONASS: BEIDOU, Galileo, GPS
Maximum Operating Temperature: + 85 C
Minimum Operating Temperature: - 40 C
