Gain: 3.6 dBi, 1.3 dbi, 2.7 dBi
VSWR: 2:1, 2.5:1
Style: I-Bar Flex
Width: 5 mm
Height: 0.1 mm
Length: 14 mm
Impedance: 50 Ohms
Cable Type: 55 mm RF0.81
Application: Wireless Application
Unit Weight: 1 g
Cable Length: 55 mm
Polarization: Linear
Power Rating: 2 W
Mounting Style: Adhesive Mount
Electrical Type: Monopole
Number of Bands: 2 Band
Center Frequency: 2.45 GHz, 5.5 GHz, 6.5 GHz
Mechanical Style: PCB Trace
Maximum Frequency: 7.125 GHz
Minimum Frequency: 2.4 GHz
Termination Style: Connector
Protocol - Sub GHz: IoT, ISM, RFID
Antenna Connector Type: U.FL Female
Protocol - WiFi - 802.11: 802.11, WiFi 6E, WLAN
Maximum Operating Temperature: + 85 C
Minimum Operating Temperature: - 40 C
Protocol - Cellular, NBIoT, LTE: DSRC
Protocol - Bluetooth, BLE - 802.15.1: Bluetooth, BLE
Protocol - ANT, Thread, Zigbee - 802.15.4: 802.15.4 (ANT, Thread, Zigbee)
