Gain: 2.33 dBi, 2.55 dBi, - 0.54 dBi, 3.25 dBi, 3.25 dBi, 3.8 dBi, 3.8 dBi, 3.47 dBi
VSWR: 3
Style: I-Bar
Width: 59.2 mm
Height: 13.6 mm
Length: 176.5 mm
IP Rating: IP65
Impedance: 50 Ohms
Cable Type: CFD-200
Application: High Speed Video, Real Time Streaming, High Capacity MIMO Networks on Public Transportation
Cable Length: 1 m
Polarization: Linear
Power Rating: 5 W
REACH - SVHC: Details
Mounting Style: Adhesive Mount
Electrical Type: Dipole
Number of Bands: 8 Band
Center Frequency: 657 MHz, 700 MHz, 850 MHz, 900 MHz, 1575 MHz, 1800 MHz, 1900 MHz, 2100 MHz, 2450 MHz, 2600 MHz, 5400 MHz
Mechanical Style: Module
Maximum Frequency: 6 GHz
Minimum Frequency: 617 MHz
Termination Style: Connector
Protocol - Sub GHz: IoT, ISM
Antenna Connector Type: SMA Male
Protocol - GPS, GLONASS: Galileo, GPS
Protocol - WiFi - 802.11: 802.11, WiFi, WLAN
Maximum Operating Temperature: + 85 C
Minimum Operating Temperature: - 40 C
Protocol - Cellular, NBIoT, LTE: 2G/3G/4G/5G NR, Cellular (NBIoT, LTE), GSM, UMTS, DCS, PCS, UMTS, EDGE, GPRS, HSPA, WCDMA
Protocol - Bluetooth, BLE - 802.15.1: Bluetooth, BLE
Protocol - ANT, Thread, Zigbee - 802.15.4: 802.15.4 (ANT, Thread, Zigbee)
