VSWR: 1.5:1, 1.5:1, 5.8
Style: Panel, Rectangular
Width: 68 mm
Height: 13 mm
Length: 205.8 mm
IP Rating: IP65
Impedance: 50 Ohms
Cable Type: 1 M RG174, 1 M TGC200 x 2
Application: HD Video over LTE, First Responder, Emergency Services, Automotive Vehicle Tracking, Telematics
Unit Weight: 330 g
Cable Length: 1 m
Polarization: Linear, RHCP
Mounting Style: Adhesive Mount
Electrical Type: Active
Number of Bands: 4 Band
Center Frequency: 700 MHz, 800 MHz, 900 MHz, 1800 MHz, 1900 MHz, 2100 MHz, 2500 MHz, 3450 MHz, 1575.42 MHz, 1602 MHz
Mechanical Style: Module
Maximum Frequency: 5.85 GHz
Minimum Frequency: 698 MHz
Termination Style: Connector
Antenna Connector Type: SMA Male, RP-SMA Male
Protocol - GPS, GLONASS: Galileo, GLONASS, GPS
Maximum Operating Temperature: + 85 C
Minimum Operating Temperature: - 40 C
Protocol - Cellular, NBIoT, LTE: 2G/3G/4G, Cellular (NBIoT, LTE), GSM, UMTS, DCS, PCS, UMTS, GPRS, WCDMA
