Gain: 3.9 dBi, 3 dBi
VSWR: 2:1, 2:1
Style: Dome
Length: 29 mm
Diameter: 49 mm
IP Rating: IP67, IP69K
Impedance: 50 Ohms
Cable Type: 1 M RG316 x 2
Technology: 2.4/5GHz Dual Band MiMo
Application: Remote Monitoring, Smart Meter Systems, Construction Equipment, Public Safety
Unit Weight: 163.610 g
Cable Length: 1 m
Polarization: Linear
Power Rating: 2 W
Mounting Style: Direct / Permanent Mount
Electrical Type: Active
Number of Bands: 2 Band
Center Frequency: 2.45 GHz, 5.5 GHz
Mechanical Style: Module
Maximum Frequency: 5.8 GHz
Minimum Frequency: 2.4 GHz
Termination Style: Connector
Protocol - Sub GHz: IoT, ISM
Antenna Connector Type: RP-SMA Male
Protocol - WiFi - 802.11: 802.11, WiFi, WLAN
Maximum Operating Temperature: + 85 C
Minimum Operating Temperature: - 40 C
Protocol - Bluetooth, BLE - 802.15.1: Bluetooth, BLE
Protocol - ANT, Thread, Zigbee - 802.15.4: 802.15.4 (ANT, Thread, Zigbee)
