Gain: 5.7 dBi, 5.29 dBi, 4.03 dBi
Style: Ceramic
Width: 15 mm
Height: 4 mm
Length: 15 mm
Impedance: 50 Ohms
Application: Access Points, Tablets, HD Video Streaming, High Data Routers, Automotive, Home Automation, Industrial Automation, Drones, Quad-Copters, UAV, Remote Control
Unit Weight: 3.500 g
Polarization: Linear
Power Rating: 10 W
Mounting Style: PCB Mount
Number of Bands: 2 Band
Center Frequency: 2.45 GHz, 5.5 GHz
Mechanical Style: Patch
Ground Plane Size: 70 mm x 70 mm
Maximum Frequency: 5.85 GHz
Minimum Frequency: 2.4 GHz
Termination Style: SMD/SMT
Moisture Sensitive: Yes
Protocol - Sub GHz: IoT, ISM
Protocol - WiFi - 802.11: 802.11, WiFi, WLAN, WiFi 6E
Maximum Operating Temperature: + 85 C
Minimum Operating Temperature: - 40 C
Protocol - Bluetooth, BLE - 802.15.1: Bluetooth, BLE
Protocol - ANT, Thread, Zigbee - 802.15.4: 802.15.4 (ANT, Thread, Zigbee)
