Width: 2.5 mm
Height: 2.3 mm
Length: 3.2 mm
Core Type: Wirewound
Shielding: Unshielded
Tolerance: 20 %
Inductance: 15 uH
Application: Automotive
Termination: Standard
Unit Weight: 50 mg
Core Material: Ferrite
Qualification: AEC-Q200
Mounting Style: PCB Mount
Test Frequency: 100 kHz
Termination Style: SMD/SMT
Maximum DC Current: 725 mA
Saturation Current: 350 mA
Maximum DC Resistance: 400 mOhms
Maximum Operating Temperature: + 155 C
Minimum Operating Temperature: - 55 C
