Characterized frequency range: 300 kHz – 6 GHz
Directivity:
300 kHz – 700 kHz > 25 dB
700 kHz – 4 GHz > 30 dB
4 GHz – 6 GHz > 20 dB
Coupling:
300 kHz – 3 GHz -20 dB ± 1 dB
3 GHz – 6 GHz -19 dB ...-16 dB
Insertion loss:
300 kHz – 1 GHz < 1.8 dB
1 GHz – 6 GHz < 2.6 dB
Max. power:
300 kHz – 6 GHz 4 W CW *)
*) Output shorted or open: max. 1 W
Operating temperature range: - 20 °C to + 40 °C
Impedance: 50 Ω
Port matching: > 20 dB
RF connectors: SMA-female
Dimensions: 170 mm x 40 mm x 32 mm
Weight: 280 g
