TEKTRONIX PWS2185 DC Power Supply (5A, 18V) | EMINKH.COM

TEKTRONIX PWS2185 DC Power Supply (5A, 18V)

Name: TEKTRONIX PWS2185 DC Power Supply (5A, 18V)
Brand: TEKTRONIX

In Stock: 1 Unit

ManufacturerTEKTRONIX(View more products from this manufacturer)

ModelPWS2185

OriginChina

Contact

Quantity

Secure Checkout

Quality Engagement

Easy change and return

Delivery Available

Accessories: Power supply, line cord, user manual, Traceable Certificate of Calibration, and documentation CD (includes user manuals and technical reference)

Specifications	PWS2185	PWS2323	PWS2326	PWS2721
DC Output Rating
Voltage	0 to 18 V	0 to 32 V	0 to 32 V	0 to 72 V
Current	0 to 5 A	0 to 3 A	0 to 6 A	0 to 1.5 A
Load Regulation
Voltage	≤0.02% + 5 mV	≤0.02% + 5 mV	≤0.04% + 6 mV	≤0.02% + 4 mV
Current	≤0.1％ + 2 mA typical
Line Regulation
Voltage	≤0.1％ + 5 mV
Current	≤0.1％ + 2 mA typical
Ripple and Noise (20 Hz to 7 MHz)
Voltage	≤1 mVRMS / 3 mVp-p
Current	≤5 mARMS
Setting Resolution
Voltage	10 mV
Current	10 mA
Setting Accuracy, (25 °C ± 5 °C)
Voltage	≤0.05% + 10 mV
Current	≤0.2％ + 10 mA
Readback Resolution
Voltage	10 mV	<20 v:="" 10="" mv="" p=""> ≥20 V: 100 mV
Current	10 mA
Readback Accuracy, (25 °C ± 5 °C)
Voltage	≤0.05% + 15 mV	<20 v:="" 0="" 05="" 15="" mv="" p=""> ≥20 V: ≤0.05% + 120 mV
Current	≤0.1％ + 15 mA
