Shutdown: No Shutdown
Input Type: Differential
Resolution: 12 bit
Output Type: Differential
Architecture: SAR
Sampling Rate: 4 GS/s, 8 GS/s
Interface Type: Serial
Mounting Style: SMD/SMT
Development Kit: ADC12DJ4000RFEVM
Moisture Sensitive: Yes
Number of Channels: 1 Channel/2 Channel
Number of Converters: 2 Converter
Supply Voltage - Max: 2 V
Supply Voltage - Min: 1.05 V
Analog Supply Voltage: 1.05 V to 1.15 V, 1.8 V to 2 V
Digital Supply Voltage: 1.05 V to 1.15 V
Pd - Power Dissipation: 4.7 W
FPBW - Full Power Bandwidth: 8 GHz
INL - Integral Nonlinearity: 1 LSB
SNR - Signal to Noise Ratio: 58.5 dBFS
Maximum Operating Temperature: + 85 C
Minimum Operating Temperature: - 40 C
DNL - Differential Nonlinearity: 0.14 LSB
ENOB - Effective Number of Bits: 9.3 bits
SFDR - Spurious Free Dynamic Range: 75 dBFS
SINAD - Signal to Noise and Distortion Ratio: 57.4 dBFS
