Width: 2 mm
Height: 0.75 mm
Length: 2 mm
Fall Time: 5 ns
Rise Time: 15 ns
Technology: Si
Unit Weight: 6 mg
Channel Mode: Enhancement
Configuration: Single
Mounting Style: SMD/SMT
Qg - Gate Charge: 4.7 nC
Number of Channels: 1 Channel
Transistor Polarity: P-Channel
Pd - Power Dissipation: 2.9 W
Vgs - Gate-Source Voltage: - 8 V, + 8 V
Typical Turn-On Delay Time: 8 ns
Typical Turn-Off Delay Time: 15 ns
Id - Continuous Drain Current: 20 A
Maximum Operating Temperature: + 150 C
Minimum Operating Temperature: - 55 C
Forward Transconductance - Min: 34 S
Rds On - Drain-Source Resistance: 19.9 mOhms
Vds - Drain-Source Breakdown Voltage: 20 V
Vgs th - Gate-Source Threshold Voltage: 1.1 V
