Width: 7.52 mm
Height: 2.55 mm
Length: 12.82 mm
Features: Adj Current Limit, Shutdown
Shutdown: Shutdown
Input Type: Rail-to-Rail
Output Type: Rail-to-Rail
Supply Type: Single
Unit Weight: 506.600 mg
Amplifier Type: Rail to Rail Operational Amplifiers
Mounting Style: SMD/SMT
SR - Slew Rate: 1.2 V/us
Voltage Gain dB: 126 dB
Moisture Sensitive: Yes
Number of Channels: 1 Channel
Supply Voltage - Max: 5.5 V
Supply Voltage - Min: 2.7 V
Ib - Input Bias Current: 10 pA
Operating Supply Current: 39 mA
Operating Supply Voltage: 2.7 V to 5.5 V
Vcm - Common Mode Voltage: Negative Rail - 0.1 V to Positive Rail + 0.1 V
Output Current per Channel: 2 A
Vos - Input Offset Voltage: 2 mV
GBP - Gain Bandwidth Product: 1.2 MHz
Maximum Operating Temperature: + 125 C
Minimum Operating Temperature: - 55 C
In - Input Noise Current Density: 0.0006 pA/sqrt Hz
en - Input Voltage Noise Density: 12 nV/sqrt Hz
CMRR - Common Mode Rejection Ratio: 100 dB
PSRR - Power Supply Rejection Ratio: 98.42 dB
