Digital I/O Port
Number of I/O Lines: 4 (Separately Configurable)
Input Level: TTL or CMOS, Voltage Tolerant up to 24 V
Output Level (Source Operation): TTL or 5 V CMOS, 2 mA Max
Output Level (Sink Operation): Open Collector, up to 24 V, 400 mA Max
Interface
USB 2.0: According to USBTMC/USBTMC-USB488 Specification Rev. 1.0
Protocol: SCPI Compliant Command Set
Drivers: VISA VXIpnp™, MS Visual Studio™, MS Visual Studio.net™, NI LabVIEW™, NI LabWindows/CVI™
General Data
Safety Features: Interlock, Inhibit, Keylock Switch, Laser Current Limit, Laser Power Limit, Soft Start, Short Circuit when Laser Off, Adjustable Laser Overvoltage Protection, Over Temperature Protection Temperature Window Protection
Display: LCD 320 x 240 Pixel
Connector for Laser, Photodiode, Interlock, and Laser On Signal: 13W3 Mixed D-Sub Jack (female)
Connector for Sensor, TE Cooler, TEC On Signal: 17W2 Mixed D-Sub Jack (female)
Connectors for Control Input / Output: BNC
Connector for Digitial I/O: Mini DIN 6
Connector for USB-Interface: USB Type B
Chassis Ground Connector: 4 mm Banana Jack
Line Voltage / Frequency: 100 to 120 V and 200 to 240 V ±10%, 50 to 60 Hz
Maximum Power Consumption: 600 VA
Mains Supply Overvoltage: Category II (Cat II)
Operating Temperature: 0 to 40°C
Storage Temperature: - 40 to +70°C
Relative Humidity: Max. 80% Up to 31°C, Decreasing to 50% at 40°C
Pollution Degree (Indoor Use Only): 2
Operation Altitude: <2000 m
Warm-up Time for Rated Accuracy: 30 min
Weight: 6.4 kg
Dimensions w/o Operating Elements (W x H x D): 263 mm x 122 mm x 307 mm (10.4" x 4.8" x 12.1")
Dimensions /w Operating Elements (W x H x D): 263 mm x 122 mm x 345 mm (10.4" x 4.8" x 13.6")
All technical data valid at 23 ± 5°C and 45 ± 15% relative humidity. Subject to change without notice.
