Optical Input Power: 20 dBm (Maximum). 22 dBm (Absolute Max.)
External Laser Wavelength Range: 1250 - 1610 nm
Power Calibration Points: 1310 nm, 1550 nm, and 1590 nm
Maximum Bit Rate (Digital Signal): 12.5 Gb/s
Small Signal Bandwidth(a): 7 GHz
Low Frequency Cutoff: 100 kHz
Amplifier RF Input (Linear Response)(b): 100 mV (Maximum)
Amplifier RF Input (Digital Mode)(c): 400 mV (Typical) 3.5 V (Maximum) 4V (Absolute Max)
Maximum Amplifier DC Input: ±15 V
Maximum Bias Voltage to Modulator: ±10 V (≥50 Ω Input Impedance)
Internal Fiber:
- PM Ports: PM PANDA-Style Fiber.
- SM Port: SMF-28-Compatible Fiber
Fiber Connectors: FC/PC, 2.0 mm Narrow Key
Electrical Connectors: SMA Female
Internal Amplifier
Rise/Fall Timed: 35 ps
RF Amplifier Gain: 34 dB
RF Amplifier Maximum Output Swing: 3 V - 7 V (Adjustable)
Electrical Return Losse: -10 dB (Typical)
Internal Control
Power Monitor Accuracy: ±0.5 dBm at Power Calibration Points
Power Monitor Resolution: 0.01 dBm
Power Monitor Insertion Loss (Typical): 0.1 dB per Monitor
VOA Insertion Loss (Typical): 0.4 dB
VOA Attenuation: 20 dB (Max)
VOA Response Tim: 1 s
(a) Linear, Analog Response
(b) <5% Total Harmonic Distortion at 1 GHz
(c) Peak to Peak
(d) Large Signal, Digital Response
(e) Any RF Port
