Maximum Drilling Diameter (mm): Ø1.5 to Ø13
Spindle Travel (mm): 60
Spindle Speed (RPM): 590 – 1000 – 1500 – 2500
Pulley Belt Type: M35 x 1
Drill Column Diameter: 60mm
Worktable Diameter: 205 x 205mm
Worktable Vertical Travel: 230mm
Distance from Spindle Center to Outer Column: 129mm
Maximum Distance from Drill Chuck to Worktable: 265mm
Distance from Drill Chuck to Base: 410mm
Motor Power: 1/2 Hp, 1450 RPM
Operating Voltage: 220V
Machine Height: 810mm
Machine Dimensions (L x W x H): 520 x 260 x 810mm
Machine Weight: 47Kg
