Roughness parameter : Ra, Rz
Tracing length: 6mm
Tracing speed : 1.0mm/sec
Cut-off lengths: 0.25mm/0.8mm/2.5mm
Evaluation length: 1.25mm/4.0mm/5.0mm
Measuring range: Ra: 0.05-6.5μm Rz: 0.1-50μm
Accuracy: ±15%
Repeatability: <12%
Filter: RC analogue
Pick-up: Piezoelectric
Radius and angle of the stylus point: Diamond, Radius : 10±2.5μm Angle: 90°(+5°or -10°)
Operating temperature: 0~40℃
Humidity: <80%
Storing temperature: -25℃ ~ 60℃
Power: 3.6V Li-ion battery
Charger: DC6V, 3 hours (charging time)
Dimension (mm): 110×70×24
Weight (g): 160
