-Measuring Method:
+pH: Glass electrode method;
+Ion: Ion electrode method
-Display: Custom LCD (simultaneous display of dual channel measured data)
-Sensor connection:
+CH1: pH、ORP、Ion
+CH2: pH、ORP、Ion
-Meas. Range:
+pH: 0.00-14.00
+ORP:0-±2000mV
+Temperature: 0-100.0℃
+Ion: differs according to the electrode that is used. (Temperature measuring function is not provided.)
-Display Range:
+pH: -2.00-16.00
+ORP: 0-±2200 mV
+Ion: 0.0μg/L-999 g/L
+Temperature: -5-110.0℃
-Repeatability (Main unit):
+pH: ±0.02 pH
+ORP: ±2 mV
+Ion: ±0.5%FS
+Temperature: ±0.2℃
-Temperature compensation: Auto/Manual Not applied to ORP and ion
-Calibration: pH/ion: Capable of three- point calibration
-Temperature Calibration: One-point calibration
-Data Memory: 1000 data points
-Auto Hold Function: Provided (Stability threshold : Fixed)
-Clock Function: Provided (To be shown while conducting a measurement)
-Interval Memory Function: Provided (Interval: The interval can be specified between 1 sec.-99 min. 59 sec. or 2 sec.-99hr. 59 min.)
-Printing Function: Can connect the external printer EPS-P30 (option)
-RS-232C Interface （non-isolated）:
+Connectable Devices: PC or external printer EPS-P30 (option)
+Communication Specifications: Communication system: Start-stop synchronous method; Baud rate: 19,200 bps;
Character length: 8 bits; Parity: None; Stop bit: 1 bit
-Analog Output （non-isolated）:
+Number of Outputs/Items:
ch1: Number of outputs: Number of outputs: 2 Measured value (not available for ion) and temperature
ch2: Number of outputs: Number of outputs: 2 Measured value (not available for ion) and temperature
+Output Specification: pH: ±700mV (pH0-14); ORP: ±1V (0-±2000mV); Temperature: 0-1V (0-100℃ )
-Waterproof Construction: IP67 (Enabled if the sensor is connected and if the external I/O portions are masked) (Can be immersed in water for 1m and 30 min.)
-Performance Compensation Temperature: 0-45℃
-Power Source: AA alkaline battery/nickel-hydrogen battery (2 pieces) or special AC adapter (6VA option)
-Power Consumption(If 3 volt battery is used)＊2: Approx. 0.004W
-Battery Life: Approx. 1500hours
-Outside Dimensions: Approx. 68 (w) x 35 (h) x 173 (d) mm
-Mass (Including Batteries): Approx. 300g
-Inluding:
+ Main unit
+ pH Sensor: GST-2729C
+ Standard solution pH 6.86, 100mL
+ Standard solution pH 6.86, 100mL
+ Internal filling solution 50mL
+ Beakers (3 pcs)
+ Hand strap: OTZ00006
+ AA battery (2pcs)
+ Connector protective cap: OTD00001
+ Manual
-Tính năng:
+ Màn hình có 2 kênh, đo đồng thời và hiển thị độ pH/Ion
+ Thiết kế tiết kiệm điện; pin có thể sạc lại được
+ Thiết kế chống thấm nước (IP67, ngâm sâu 1m, tối đa 30 phút)
+ Lưu trữ dữ liệu lên đến 1000 dữ điểm
+ PC và máy in ngoài có thể kết nối
Các hạng mục đo lường:
pH, ORP, Ion, nhiệt độ
(Các điện cực ORP và Ion được bán riêng)
Ứng dụng: Dùng để độ pH, ORP, Ion, nhiệt độ trong phòng thí nghiệm
Datasheet
