Power: 3.5 KW
Furnace tube size(mm): Material: nickel-based alloy steels Dia 50(ID30) X1000
Dimension: 580X370X515
Power supply voltage: 220V
Phase number: Single-phase
Temperature control mode
1.Yudian temperature control: 30 sections can only use PID temperature regulation.
2.FP93 temperature control (from Japan)
Control accuracy: +/- 1 ℃
Water-cooled
When furnace heating needs water-cooled,
Required water flow ≥ 35L / min, water temperature <30ºC;
water pressure> 25 PSI.
Trigger: Phase-shift trigger
SCR: 106 / 16E Germany Simon Kang
The 1.2 temperature zone max temperature
20Mpa temperature ≤800 ° C
12Mpa temperature ≤900 ° C
6Mpa temperatures ≤1000 ° C
4Mpa temperatures ≤1100 ° C
The 1.2 rated temperature
1100 ℃ ≤ 1h
1000 degrees can work long time
Heating rate: ≤10 ℃/ Min (Available upon request modification)
Thermocouple Type: K type
The first temperature zone heating section length: 205mm
The second temperature zone heating section length: 205mm
Vacuum degree （Optional）
1.General vacuum and drive gas out by:TW-1.5A
2.2XZ-2 Vacuum degree pumps can be able to get around 10Pa
3.TOB-DSP-VS 0.1vacuum system can pumped 0.1Pa
4、TOB-DSP-VS high vacuum system enables vacuum degree pumped 10-3 Pa.
Pressure display: Digital pressure gauge, and with 4-20ml Model Output
Vacuum flange
CF flange
Oxygen-free copper gasket seal
Surrounding surface temperature: ≤45℃
Security System: overcurrent protection.
Cap protection system: when the lid open relay will automatically cut off the main power supply, effectively ensure the safety of users
