Power: 8KW
Furnace tube size(mm): 300X200X200
Dimension: 600X610X860
Power supply voltage: 220V
Phase number: Single-phase
Heating element: 1800 type Molybdenum Wire
Temperature control mode: FP93 temperature control (from Japan)
Control accuracy: +/- 1 ℃
Triggers
1.Phase trigger (with soft start and current limiting function)
2.Current limiting function: furnace transformer secondary current through the post is limited to 160A,
3.Soft-start function
SCR: 106 / 16E Germany Semikron
Max temperature: 1700℃
Rated temperature: 1650 ℃
Vacuum degree in cold state: ≤100Pa
Heating rate: ≤20 ℃ / Min (available upon request modification)
Recommended heating rate: ≤10 ℃ / Min
Thermocouple Type: Type B
Certification: CE
Surrounding surface temperature: ≤45℃
Maximum temperature use in a variety of atmosphere
AtmosphereMax temperature
He,Ar,Ne1700℃
H2 (70%), N2 (30%)1700℃
Mixed gas1700℃
H21700℃
He, Ar, Ne and H21700℃
A mixed gas,1700℃
H2 may be any content1700℃
