Output impedance: 100Ω, ±1% @1kHz
Frequency:
- Range: 20Hz-1MHz
- Resolution:
100.000Hz - 999.999Hz 1mHz
1.00000kHz - 9.99999kHz 10mHz
10.0000kHz - 99.9999kHz 0.1Hz
100.000kHz - 999.999kHz 1Hz
1.00000MHz - 2.00000MHz 10Hz
Test parameter:
Cp-D,Cp-Q,Cp-G,Cp-Rp
Cs-D,Cs-Q,Cs-Rs
Lp-D, Lp-Q, Lp-G, Lp-Rp, Lp-Rdc
Ls-D, Ls-Q, Ls-Rs, Ls-Rdc, Rdc
R-X, Z-θd, Z-θr
G-B, Y-θd, Y-θr
Vdc-Idc
Range:
- LCR: 100mΩ, 1Ω, 10Ω, 20Ω, 50Ω, 100Ω, 200Ω, 500Ω, 1kΩ, 2kΩ, 5kΩ, 10kΩ, 20kΩ, 50kΩ, 100kΩ, total 15 ranges
- Rdc: 1Ω, 10Ω, 20Ω, 50Ω, 100Ω, 200Ω, 500Ω, 1kΩ, 2kΩ, 5kΩ, 10kΩ, 20kΩ, 50kΩ, 100kΩ, total 15 ranges
Test display range: (a 1×10-18 ; E 1×1018)
- Cs, Cp: ±1.000000 aF -- 999.9999 EF
- Ls,Lp: ±1.000000 aH -- 999.9999 EH
- D: ±0.000001 -- 9.999999
- Q: ±0.01 -- 99999.99
- R, Rs, Rp, X, Z, Rdc: ±1.000000 aΩ -- 999.9999 EΩ
- G,B,Y: ±1. 000000 aS -- 999.9999 ES
- Vdc: ±1.000000 aV -- 999.9999 EV
- Idc: ±1.000000 aA -- 999.9999 EA
- θ r: ±1.000000 a rad -- 3.141593 rad
- θ d: ±0.0001 deg -- 180.0000 deg
- Δ%: ±0.0001% -- 999.9999%
- t: -99.99°C -- 1000.00°C
