Rated value:
- Power: 350W
- Voltage: 500V
- Voltage: 30A
- Min. Operation Voltage: 3V at 30A
- Min. Rising Time: 20uS
Static Mode: Constant Current (CC) Mode, Constant Resistance (CR) Mode, Constant Voltage (CV) Mode, and Constant Power (CP) Mode.
Voltage:
- Range: 0~50V/0~500V
- Setting:
Resolution: 0.2mV/2mV
Accuracy: 0.05%+0.05%FS
- Measurement:
Resolution: 1mV/10mV
Accuracy: 0.08%+0.05%FS
Current:
- Range: 0~3A/0~30A
- Setting:
Resolution: 0.05mA/0.5mA
Accuracy: 0.05%+0.05%FS
- Measurement:
Resolution: 0.1mA/1mA
Accuracy: 0.08%+0.05%FS
Resistance:
- Range: 0.1Ω~30kΩ
- Resolution: 0.1Ω
- Accuracy: 1%
Power:
- Range: 0~350w
- Resolution: 10mW
- Accuracy: 0.5%+0.1%FS
Dynamic Mode:
- Range: 20 uS ~ 60S
- Resolution: 2 uS
- Accuracy: 1us+100ppm
- Rising Slope: 0.6A/ms~1.5A/µs
Ripple:
- Range: 0~50V/ 0~500V
- Band Width: 250kHz
- Accuracy: 0.1%
Protection Function: Over Voltage Protection (OVP), Over Current Protection(OCO), Over Power Protection(OPP).
Storage: Internal 20 groups
General Specification
Volume(W*H*D): 350mm*122mm*425mm
Weight: 4.8kg
Power Source: Power source voltage: 220V(1±10%)，Power source frequency: 50Hz/60Hz(1±5%)，Power Consumption: <50VA
Temperature and Humidity: 0℃～40℃，Humidity: < 90%RH
