Unit Weight: 6.800 mg
Configuration: Dual
Mounting Style: SMD/SMT
Number of Channels: 2 Channel
Transistor Polarity: NPN, PNP
Pd - Power Dissipation: 200 mW
Typical Input Resistor: 2.2 kOhms
Typical Resistor Ratio: 0.0468
Emitter- Base Voltage VEBO: 5 V
Maximum Operating Frequency: 250 MHz, 200 MHz
Continuous Collector Current: 100 mA
Maximum Operating Temperature: + 150 C
Minimum Operating Temperature: - 55 C
DC Collector/Base Gain hfe Min: 80
Collector- Emitter Voltage VCEO Max: 50 V
