TQCSheen GL0030 Glossmeter (0-2000GU/0-1000GU/0-160GU)

Specifications:

Traverse speed: 1 - 60 cycles per minute

Calibration standard: Integrated tile in the dust cover

Display: LED display

Light source: Extreme low drift LED light source

Readings per batch: max 500, non-dependent of number of angles

Total max readings: 2000 readings with time stamp

Scan function: Yes

Statistics: Min. / Max. / Avg. / Std.dev / number of measurements

Security: Password protection

Software: Ideal Finish Analysis

Dimensions:

Size: 90x140x45mm / 3.54x5.551x1.7" (h x w x d)

Mass: 398g

Measurement:

Base dimensions: 5x130mm/1.7x5.12

Measurement speed: 70 measurements per minute at 3 angles simultaneously

Measurement: 3 geometries

Units: Gloss Units (GU)

Resolutions: 0.1 GU (0-100GU)

1GU (>100GU)

Range: 0-2000 GU (20˚); 0-1000 GU (60˚); 0-160 GU (85˚)

Repeatability r: 0.4 GU (20˚); 0.2 GU (60˚); 0.2 GU (85˚)

Reproducibility R: 1.69 GU (20˚); 1.58 GU (60˚); 1.88 GU (85˚)

Scope of Supply:

Glossmeter

2x AA type batteries

Plastic case

Screwdriver

USB stick with Ideal Finish Analysis software

Microfiber cleaning towel

USB cable

Calibration certificate

Datasheet

Manual
