Width: 14.4 mm (0.567 in)
Height: 10.2 mm (0.402 in)
Length: 24.3 mm (0.957 in)
Industry: Medical
Unit Weight: 7 g
Output Power: 3.5 W
Input Voltage: 36 V to 75 V
Mounting Style: Through Hole
Isolation Voltage: 5 kV
Number of Outputs: 2 Output
Input Voltage - Max: 75 V
Input Voltage - Min: 36 V
Input Voltage, Nominal: 48 V
Output Current-Channel 1: 146 mA
Output Current-Channel 2: 146 mA
Output Voltage-Channel 1: 12 V
Output Voltage-Channel 2: - 12 V
Maximum Operating Temperature: + 95 C
Minimum Operating Temperature: - 40 C
