Width: 43.2 mm
Height: 23 mm
Length: 55.1 mm
Industry: Industrial
Approvals: EN 60335-1, IEC/EN/UL 62368-4
Dimensions: 43.2 mm x 23 mm x 55.1 mm
Efficiency: 85 %
Unit Weight: 65 g
Output Power: 10 W
Input Voltage: 90 VAC to 305 VAC, 100 VDC to 250 VDC
Mounting Style: Chassis
Input Frequency: 47 Hz to 63 Hz
Load Regulation: Regulated
Isolation Voltage: 4 kVAC
Number of Outputs: 1 Output
Open Frame/Enclosed: Enclosed
Output Current-Channel 1: 833 mA
Output Voltage-Channel 1: 12 VDC
Maximum Operating Temperature: + 70 C
Minimum Operating Temperature: - 40 C
