Width: 9.3 mm (0.366 in)
Height: 11.2 mm (0.441 in)
Length: 21.8 mm (0.858 in)
Industry: Industrial
Compliance: IEC/EN/UL 62368-1
Unit Weight: 4.800 g
Output Power: 4 W
Input Voltage: 9 V to 18 V
Mounting Style: Through Hole
Isolation Voltage: 1.6 kV
Number of Outputs: 2 Output
Input Voltage - Max: 18 V
Input Voltage - Min: 9 V
Input Voltage, Nominal: 12 V
Output Current-Channel 1: 166 mA
Output Current-Channel 2: 166 mA
Output Voltage-Channel 1: 12 V
Output Voltage-Channel 2: - 12 V
Maximum Operating Temperature: + 85 C
Minimum Operating Temperature: - 40 C
