Width: 20.3 mm (0.799 in)
Height: 12 mm (0.472 in)
Length: 31.8 mm (1.252 in)
Industry: Industrial
Unit Weight: 16 g
Output Power: 10 W
Input Voltage: 36 V to 75 V
Mounting Style: Through Hole
Isolation Voltage: 9 kV
Number of Outputs: 2 Output
Input Voltage - Max: 75 V
Input Voltage - Min: 36 V
Input Voltage, Nominal: 48 V
Output Current-Channel 1: 416 mA
Output Current-Channel 2: 416 mA
Output Voltage-Channel 1: 12 V
Output Voltage-Channel 2: - 12 V
Maximum Operating Temperature: + 85 C
Minimum Operating Temperature: - 40 C
