Width: 9.6 mm (0.378 in)
Height: 11.2 mm (0.441 in)
Length: 21.8 mm (0.858 in)
Industry: Industrial
Unit Weight: 6 g
Output Power: 3 W
Input Voltage: 18 V to 36 V
Mounting Style: Through Hole
Isolation Voltage: 1.6 kV
Number of Outputs: 2 Output
Input Voltage - Max: 36 V
Input Voltage - Min: 18 V
Input Voltage, Nominal: 24 V
Output Current-Channel 1: 300 mA
Output Current-Channel 2: 300 mA
Output Voltage-Channel 1: 5 V
Output Voltage-Channel 2: - 5 V
Maximum Operating Temperature: + 90 C
Minimum Operating Temperature: - 40 C
