Width: 99 mm (3.898 in)
Height: 50.3 mm (1.98 in)
Length: 199 mm (7.835 in)
Industry: Industrial
Approvals: IEC/EN/UL60950-1
Compliance: IEC/EN/UL 60950-1
Efficiency: 88.5 %
Unit Weight: 700 g
Output Power: 200 W
Input Voltage: 90 VAC to 264 VAC, 120 VDC to 370 VDC
Mounting Style: Chassis
Input Frequency: 47 Hz to 63 Hz
Load Regulation: Regulated
Isolation Voltage: 3 kVrms
Number of Outputs: 1 Output
Open Frame/Enclosed: Enclosed
Output Current-Channel 1: 4.2 A
Output Voltage-Channel 1: 48 VDC
Operating Temperature Range: - 20 C to + 65 C
Maximum Operating Temperature: + 65 C
Minimum Operating Temperature: - 20 C
