Weight: 372 g (incl. batteries)
Dimensions (height x width x depth): 243 x 87 x 44 mm
Max. diameter of conductor :Approx. 38 mm
Measuring rate: 3 per second
Input resistance (VAC and VDC): 10 MΩ
Frequency range alternating current: 50/60 Hz (AAC)
Frequency range AC voltage: 40–400 Hz (VAC)
Ambient conditions: 0 °C to 40 °C with up to 75 % RH
Storage conditions: -30 °C to 60 °C with up to 85 % RH
Type of protection: IP20
Batteries: 3 x 1.5 V AAA
Overvoltage protection: Category lll 1000 V
Measuring ranges
AC voltage (V/AC): 6V~750V
DC voltage (V/DC): 6V~1000V
Alternating current (A/AC): 60A~1000A
Direct current (A/DC): 6A~1000A
Resistance (Ω): 600 Ω~60 MΩ
Frequency using measuring cables (Hz): 9.999 Hz~9.999 MHz
Frequency using clamp (Hz): 40 Hz - 999.9 Hz
Duty cycle: 5 % ~ 95 %
Capacitance (C): 40 nF~4000 µF
Scope of delivery
• 1 x Device
• 1 x Red measuring cable
• 1 x Black measuring cable
• 1 x Label with safety information
• 3 x 1.5 V battery AAA
• 1 x Manual
