Technical data:
Idle speed 1. Speed level: 50 - 3.000 min-1
Impact frequency combined 1. Speed level: 800 - 48.000 min-1
Max. torque (decimal digit) [Nm]: 7.5
Tool holder: Quick-release chuck
Max. chucking range [mm]: 13
Maximum drilling diameter:
Wood [mm]: 30
Metal [mm]: 10
Masonry / bricks [mm]: 13
Electrical values:
Mains connection: 230 V, 50 Hz
Power input [W]: 650
Connection plug: CEE 7/17
Cable length [m]: 3
Protection class: II
Sound values according to EN 62841:
Sound pressure level [dB(A)]: 95
Sound power level [dB(A)]: 106
Uncertainty K [dB]: 5
Vibration information according to EN 62841:
Vibration emission value (ah) Impact drilling in brickwork with main handle [m/s²]: 21.795
Uncertainty (K) Impact drilling in brickwork with main handle [m/s²]: 1.5
Vibration emission value (ah) Impact drilling in brickwork with additional handle [m/s²]: 12.605
Uncertainty (K) Impact drilling in brickwork with additional handle [m/s²]: 1.5
Vibration emission value (ah) Drilling in metal with main handle [m/s²]: 4.041
Uncertainty (K) Drilling in metal with main handle [m/s²]: 1.5
Vibration emission value (ah) Drilling in metal with additional handle [m/s²]: 2.713
Uncertainty (K) Drilling in metal with additional handle [m/s²]: 1.5
Dimensions:
Length (packaging excluded) [mm]: 200
Width (packaging excluded) [mm]: 60
Height (packaging excluded) [mm]: 300
Weight:
(packaging excluded) [kg]: 2
