Technical data:
Number of speed levels: 2
Idle speed 1. Speed level: 0 - 440
Idle speed 2. Speed level: 0 - 1.650
Impact frequency combined 1. Speed level: 0 - 26.400 min-1
Number of torque settings: 20 + 1 + 1 (impact drilling setting)
Max. torque [Nm]: 40
Tool holder: Quick-release chuck
Max. chucking range [mm]: 13
Maximum drilling diameter:
Wood [mm]: 30
Metal [mm]: 13
Masonry / bricks [mm]: 15
Sound values according to EN 62841:
Sound pressure level [dB(A)]: 74.34
Sound power level [dB(A)]: 85.34
Uncertainty K [dB]: 5
Vibration information according to EN 62841:
Vibration emission value impact drilling in brickwork (ah) [m/s²]: 14.493
Uncertainty (K) impact drilling in brickwork: 1.5
Vibration emission value for drilling in metal (ah) [m/s²]: 0.925
Uncertainty (K) drilling in metal: 1.5
Electrical values battery:
Battery nominal voltage [V]: 20
Battery capacity [Ah]: 2
Capacity indication: 3-stage
Battery type: Li-ion
Battery charging time [h]: 1
Charger:
Mains connection: 230 - 240 V, 50 Hz
Output voltage [V]: 21.5
Power input [W]: 65
Nominal current consumption [mA]: 2400
Connection plug: CEE 7/16
Cable length [m]: 1.5
Protection class: II
Dimensions:
Length (packaging excluded) [mm]: 225
Width (packaging excluded) [mm]: 80
Height (packaging excluded) [mm]: 230
Weight:
(packaging excluded) [kg]: 2
