Technical data:
Idle speed: 0 - 12.000 min-1
Planing width [mm]: 82
Cutting depth: 0 – 1.5 mm
Rebating depth: max. 10 mm
Sound values according to EN 62841:
Sound pressure level [dB(A)]: 96
Sound power level [dB(A)]: 85
Uncertainty (K) [dB]: 3
Weighted acceleration, typically:
Hand-arm-vibration ah [m/s²]: 1.2
Uncertainty (K) [m/s²]: 1.5
Electrical values battery:
Battery nominal voltage [V]: 20
Battery capacity [Ah]: 4
Capacity indication: 3-stage
Battery type: Li-ion
Battery charging time [h]: 1.5
Charger:
Mains connection: 230 - 240 V, 50 Hz
Output voltage [V]: 21.5
Power input [W]: 94
Nominal current consumption [mA]: 3500
Connection plug: CEE 7/16
Cable length [m]: 1.5
Protection class: II
Dimensions:
Length (packaging excluded) [mm]: 321
Width (packaging excluded) [mm]: 168
Height (packaging excluded) [mm]: 175
Weight:
(packaging excluded) [kg]: 2
