Distance measurement:
Min. measuring range [m]: 0.05
Max. measuring range [m]: 120
Min. measuring range [ft]: 0.2
Max. measuring range [ft]: 394
Resolution: 1 mm
Typical measuring tolerance: +/-1.5 mm
Inclination measurement:
Measuring range | Inclination measurement: 360 °
Messgenauigkeit typ.: ±0.5°
Laser:
Ø of the laser point at distance 10 m [mm]: 10
Ø of the laser point at distance 20 m [mm]: 20
Ø of the laser point at distance 30 m [mm]: 30
class: 2
output < [mW]: 1
Memory organisation: Store up to 99 measurements
Display:
Backlit display: ✓
Monochrome: ✓
Device control: Push buttons: ✓
Interfaces:
Bluetooth: -
Micro-USB: -
Housing design: Plastics: ✓
Type of protection: IP40: ✓
Power supply: Internal (battery): 2 x 1.5V AAA
Ambient conditions:
Operation - min. temperature [°C]: -10
Operation - max. temperature [°C]: 50
Operation - min. temperature [°F]: 14
Operation - max. temperature [°F]: 122
Storage - min. temperature [°C]: -20
Storage - max. temperature [°C]: 60
Dimensions:
Length (packaging excluded) [mm]: 27
Width (packaging excluded) [mm]: 50
Height (packaging excluded) [mm]: 115
Weight: (packaging excluded) [kg]: 0.128
