Distance measurement:
Min. measuring range [m]: 0.2
Max. measuring range [m]: 200
Resolution: 0.1 mm
Typical measuring tolerance: +/-2 mm
Inclination measurement:
Measuring range | Inclination measurement: 360°
Messgenauigkeit typ.: ±0,3°
Laser:
Ø of the laser point at distance 10 m [mm]: 6
Ø of the laser point at distance 20 m [mm]: 11
Ø of the laser point at distance 30 m [mm]: 18
class: 2
output < [mW]: 1
Wavelength [nm]: 630 - 670 nm
Memory organisation:
Saving of up to 1.000 measurements: ✓
Saving of up to 100 screenshots: ✓
Display:
3" HD colour display: ✓
hintergrundbeleuchtet: -
Monochrome: -
Device control:
Push buttons: ✓
Interfaces:
Micro USB: ✓
Bluetooth: ✓
Housing design: Plastics: ✓
Type of protection: IP65: ✓
Power supply: Internal (battery): 3 x 1.2V AAA Ni-MH
Ambient conditions:
Operation - min. temperature [°C]: 0
Operation - max. temperature [°C]: 40
Storage - min. temperature [°C]: -10
Storage - max. temperature [°C]: 60
Dimensions:
Length (packaging excluded) [mm]: 28
Width (packaging excluded) [mm]: 54
Height (packaging excluded) [mm]: 130
Weight: (packaging excluded) [kg]: 0.19
