Resolution: 1920*1080 Full HD
Frame rate: 60fps
Voltage: 12VDC
Connection: HDMI, USB
Accessory:
- Light Source
- Plan 5x,10x,20x,50x
- HDMI cable
- 12V source
- Base and Holder
Optical system: Infinitely chromatic aberration corrected bright field optical system
Observation lens:
30° tilt, infinity hinged binocular barrel, pupil adjustment: 54mm-75mm, unilateral image adjustment: +5 diopters
30° tilt, infinity hinged binoculars, pupil adjustment: 54mm-75mm, unilateral vision adjustment: ±5 diopters, two spectral ratios R:T = 100:0 or 50:50
Ocular: High eye point large field flat field eyepiece PL10X22mm
Lens: Long working field infinity bright field objective lens (5x, 10x, 20x, 50x)
Convert objective lens: Five hole adapter located inside
Focus mechanism:
Multi-purpose frame, low hand position coaxial coarse and micro focusing mechanism, coarse adjustment stroke 28mm, fine adjustment precision 0.002mm. with anti-slip adjustment elastic device and random upper limit device. With up platform position and coarse and fine focusing adjustment mechanism, maximum sample height 28mm.
Reflector frame, low hand position coarse and micro coaxial focusing mechanism, coarse adjustment stroke 28mm, fine adjustment precision 0.002mm, with anti-slip adjustment elastic device and random upper limit device. With platform position up and down adjustment mechanism, maximum sample height 78mm.
Size: Double layer mechanical moving platform, X low arm position, Y direction coaxial adjustment; platform area 175X145mm, moving range: 76mmX42mm can be equipped with reflective metal carrier plate, reflective cross-sectional dual-purpose glass carrier plate
Lighting system above: Adaptive wide voltage 100V-240V AC50/60Hz, reflective light room, single high power 5WLED, Warm color top lighting system, Cora lighting, with field of view diaphragm and aperture diaphragm, adjustable center, with oblique lighting device
Low lighting system: Wide voltage adaptable 100V-240V AC50/60Hz, transmission chamber, single high power 5WLED,
Concentrator: Rotating-out color concentrator (N.AO.9) with variable aperture diaphragm, adjustable center
Other accessories
Color filters for transmission: yellow, IF550 filter, LBD filter, neutral filter
Camera Accessories: 0.5X C Connector
Interference filter for reflection: < blue = 480nm; green 520nm-570nm; red 630-750nmLBD
