- MAXIMUM INPUT RATINGS:
Current: 16A
Voltage: 500V
Power: 400W
Minimum Operating: 10V
Minimum Effectve Resistance: 1Ω
Off State Leakage: <5mA
Reverse Polarity: 16A
Isolaton Voltage: CAT II (300V)
Input Terminals: 4mm plugs at 16A
- OPERATING MODES:
CC MODE:
Range: 0-16A
Accuracy: ± 0.2% ± 30mA
Resoluton: 1mA
Regulaton: < 30 mA for 90% load power change (Volts > 25V)
Temperature Coefficient: < (±0·02% ± 5 mA) per °C
(2) Slew Rate Range: <5A per s to >500A per ms
Minimum Transiton Time: (4) 50µs
- CP MODE:
Range: 0-400W
Accuracy: ± 0·5% ± 2W ± 30 mA (Volts > 25V)
Resolution: 100mW
Regulation: < 2% over 25V to 550V source voltage change
Temperature Coefcient: < (± 0·1% ± 5 mA) per °C
- CP MODE CONT.
(2) Slew Rate Range: 60W per s to 6000W per ms
Minimum Transiton Time: (4)150µs
CR MODE Range: 50Ω-10kΩ
Accuracy: ±0·5% ± 2 digits ± 30mA (Volts > 25V)
Resolution: 1Ω
Regulation: < 2% for 90% load power change (Volts > 25V)
Temperature Coefcient: < (±0·04% ± 5 mA ) per °C
(2) Slew Rate Range: 1Ω per ms to 100Ω per µs
Minimum Transiton Time: (4) 150 µs
- CG MODE:
Range: 0·001-1 A/V
Accuracy: ± 0·5% ± 2 digits ± 30mA (Volts > 25V)
Resolution: 1 mA/V
Regulation: < 2% for 90% load power change (Volts > 25V)
Temperature Coefcient: < (±0·04% ± 5mA) per °C
(2) Slew Rate Range: <0·1A/V per s to >10A/V per ms
Minimum Transiton Time: (4) 150µs
- METER SPECIFICATIONS:
Display Type: 256 x112 pixel graphic LCD with white LED backlight.
MEASURED VALUES:
Volts & Amps: Measured values of current through and voltage across the load.
Wat & Ohms: Power and equivalent load resistance, calculated from Volts and Amps.
Voltage Accuracy: ± 0·1% ± 0.02%FS
Current Accuracy: ± 0·2% ± 0.04%FS
- GENERAL:
AC Input: 110V–120V or 220V–240V AC ±10%, 50/60Hz.
Installaton Category II
Power Consumption: 40VA max. Mains lead rating: 6A minimum. 40VA max. Mains lead
ratng: 6A minimum.
Operating Range: + 5°C to + 40°C, 20% to 80% RH
Storage Range: – 40°C to + 70°C
Environmental: Indoor use at altitudes up to 2000m, Pollution Degree 2.
Cooling: Variable speed fan. Air exit at rear.
Safety: Complies with EN61010-1
EMC: Complies with EN61326
Size: 130mm H (3U) x 212mm W (½ rack) x 435mm D
Weight: 5.7 kg
Option: RM460 - 19-inch rack mount kit
GPIB interfaces: no, this feature has been discontinued
