- Three-phase ACV measurement:
Range: 240V
Resolution: 0.1 mV
Accuracy ( ± ppm of reading + ppm of range) [1]: 400 + 100
Temp. Coefficient, ± ppm*RD /°C @-25℃~55℃: 30
Measurement range: 30 V ~ 300 V
- Three-phase ACI measurement:
Range: 60A ~ 100 mA
Resolution: 0.1 μA ~ 10 μA
Accuracy ( ± ppm of reading + ppm of range): 400 + 100
Temp. Coefficient, ± ppm*RD /°C @-25℃~55℃: 50
Measurement range: 10 mA ~ 78 A:
- P/E Energy Measurement
Active power/electrical energy |cosΦ| ≥0.5: Accuracy: 0.1%*RD
- Temperature Clock:
DC power / electrical energy
Range: -30℃~60℃
Accuracy: 0.3℃
Clock function
Timing mode: GPS clock timing
Accuracy: 1s/d
-General Specifications:
Power supply mode: EV charger, built-in lithium battery, 220V commercial power
Power supply: AC ( 220 ± 22 ) V, ( 50 ± 2 ) Hz
Max. Power: 80 VA
Communication interface: USB, LAN, WIFI
Temperature performance: Operating temperature: -25°C~55°C; Storage temperature: -30°C~70°C
Humidity Performance: Operating humidity: < 80% @ 30°C, < 70% @ 40°C, < 40% @ 50°C; Storage humidity: <80% R•H, non-condensing。
Altitude: < 3000 m
Weight: About 13 kg
Dimensions: 390 mm（W）× 400 mm（D）× 260 mm（H）
