Capacity: 63L to 6000L
Cooling rate: 2-3℃/min (standard), 5℃/min, 10℃/min , 20℃/min as option
Vibration: maximum up to 5000kgf, 100g
Inner chamber size(mm)W*H*D: 1000*1000*800
Exterior chamber size(mm)W*H*D: 1900*1200*1320
Max table-board size of vibrostand (mm)
- Horizontal: 400*400
- Vertical: 400*400
Temperature range: -160℃,-140℃,-120℃,-100℃,-80℃,-70℃,-60℃,-40℃,-20℃,0℃~+150℃,200℃,250℃,300℃,400℃,500℃
Humidity range: 20%~98%R.H (10%~98%R.H;5%~98%R.H Optional)
Temp.&Humi fluctuation: ±0.5℃, ±2%.
Temp.Humi.Uniformity: ±1℃, ±2%.
Temp.humi Deviation: ≤±2℃/ ±3%RH.
Heating up time: About 3~4℃/min.(Customized requirements:Fast temperature change rate:5℃~25℃/min,linear average or nonlinear average).
Cooling down time: About 0.7℃~1℃/min (Customized requirements:Fast temperature change rate:5℃~25℃/min,linear average or nonlinear average).
Material:
- Inner chamber material: SUS#304 stainless steel plate
- Exterior chamber material: Stainless steel plate+ powder coated
- Insulation material: PU & Fiberglass wool
Accessories: Multi-layer vacuum glass observation window,Cable port(50mm),Controlling status indicator lamp,Chamber light,Specimen loading shelf(2pcs,position adjustable),Guaze 5pcs,Operation manual 1 set.
