Construction: ABS/Polylend Blend Plastic Shielded
Circuitry: Solid State Analog and SMD Digital Circuitry with temperature compensation and true RMS conversion
Frequency Range: 20 kHz to 100kHz (tunable in 1kHz increments)
Response Time: < 0ms
Display: QVGA touch screen – IR, Laser Pointer, Camera, Spectrum Analyzer
Sound Recording: WAV file format
IR Temperature: -20°C to 500°C
Camera: 5.0 Mega Pixel
Laser: Output power < 1mW – Wavelength 640nm – Class II Laser Product
Memory: 32 GB
Battery: Lithium ION Rechargeable
Operating Temperature: 0°F to 122°F (-18°C to 50°C)
Outputs: Calibrated heterodyned output, decibel (dB) frequency, SD card, Wi-Fi – Supported wireless standards n,b,g – Frequency 2.4 GHz – Security TKIP, AES, WPA and WPA2
Bluetooth: Version 4.2 – Supported profile A2DP – Frequency range 2.4GHz
Probes: Trisonic Scanning Module and Stethoscope Module, Long Range Module and RAS-MT
Headsets: Deluxe noise attenuating headphones - for hard hat use * Optional Bluetooth headsets available
Indicators: dB, Frequency, Battery Status and 16 Segment Bar Graph
Sensitivity: Detects .127 mm (.005") diameter leak @ .34 bar (5 psi) at a distance of 15.24 m (50 ft.) *
Threshold: 1x10^-2 std.cc/sec to 1x10^-3 std.cc/sec
Dimensions: Complete kit in aluminum carrying case 55x47x20 cm(21.5"x18.5"x8")
Weight: Pistol Unit:11kg(235lbs.), COMPLETE CARRYING CASE: 8.6kg(19lbs)
Warranty: 5 years parts/labor
Display Modes: dB(main), IR, ABCD, Spectrum and Application Specific; Spectrum Analyzer modes: Spectrum, Time Series & Dual Specific
Ultraprobe15,000 KIT: Meets and exceeds ASTM E1002–2005 requirements for Leak Detection depending upon leak configuration.
