Detector Data:
Type: Uncooled FPA
IR resolution: 384×288
Pixel pitch: 17μm
Spectral range: 7.5～14μm
NETD/Sensitivity: 65mK
Infrared lens:
FOV: 40°× 30°
Minimum imaging distance :50cm
IFOV: 1.889 mrad
Focus Fixed:
Lens Data: 9mm
Visible light camera:
Sensor type: 1/2.8"SONY Progressive Scan CMOS
Audio video:
Main stream: 1920*1080/1280*720 (Frame rate1~30fps adjustable)
Sub stream: 704*576/640*480/640*352/320*240 (Frame rate1~30fps adjustable)
Computer: Support IE6.0 and above version, Firefox, Google
Online browsing users: Support up to 5 users
Shell applicable environment: Aluminum alloy material, suitable for outdoor
Installation mode: Bracket installation
Temperature range: 30~45℃ error ±0.5℃ External blackbody mode accuracy±0.3℃
(External black body correction mode ±0.3℃)
Working environment: 16°C~35 °C
Humidity: 0% -85% RH
Power supply: DC12V 2A
Power consumption: <12W
Size: L335×W189×H107mm
Weight: <2500g
