DC voltage: 1000V ±(0.25%+5)
AC voltage: 1000V ±(0.3%+30)
DC current (A): 10A ±(0.08%+10)
AC current (A): 10A ±(0.6%+20)
Resistance (Ω): 60.00MΩ ±(0.05%+2)
Admittance (nS): 60nS ±(2%+10)
Capacitance: 60.00mF ±(2%+5)
Frequency: 10Hz ~ 60MHz ±(0.01%+5)
Temperature (°C): -40°C~1000°C ±(1%+30)
Temperature (°F): -40°F~1832°F±(1.5%+50)
Duty cycle: 10% ~ 90% ±(2%+5)
Display count: 60000
Dual temperature measurement: T1, T2, T1-T2, T2-T1
Data hold/Peak hold: Yes
Relative mode: Yes
Data logging: 20000
Trend capture: Yes
MAX/MIN/AVG: Yes
Data time display/Data comparison: Yes
Backlight adjustment: Yes
Analog bar graph/USB interface: Yes
Mis-plug alarm: Yes
Battery indication/Auto power off: Yes
Rechargeable battery: Yes
Input protection: Yes
Input impedance for DCV: ≥10MΩ
1m drop test: Yes
Safety rating: IP65
Power supply: Li-ion battery: 7.4V 2200mAh
Display: 3.5-inch 64K color TFT LCD (320 x 240)
Device color: Red and grey
Device weight: 638.6g
Device size: 225mm x 103mm x 59mm
Standard accessories: Battery, test leads, temperature adaptor socket,
point contact temperature probes, power adaptor socket, power adaptor, PC software CD, USB interface cable
