AC Current (A): 600.00uA/6000.0uA/60.000mA/600.00mA/6.0000A/10.000A ±(0.5%+50)
DC Current (A): 600.00uA/6000.0uA/60.000mA/600.00mA/6.0000A/10.000A ±(0.1%+20)
AC+DC Current (A) : 600.0uA/6000uA/60.00mA/600.0mA/6.000A/10.00A ±(1.0%+5)
AC Voltage (V): 600.00mV/6.0000V/60.000V/600.00V/1000.0V ±(0.3%+20)
Voltage (DCV) (60000 count): 600.00mV/6.0000V/60.000V/600.00V/1000.0V ±(0.03%+5)
Voltage (DCV) (600000 count): 600.000mV/6.00000V/60.0000V/600.000V/1000.00V ±(0.015%+10)
Auto AC/DC Voltage: 600.0V ±（0.8％＋5）
Voltage Range (ACV+DCV): 600.0mV/6.000V/60.00V/600.0V/1000V ±（0.8％＋5）
Externalcurrent (DC) (Optional: UT-CS07): 100.0A（(10mV/A)/1000A(1V/A) ±(1.5%+5)
Externalcurrent (AC) (Optional: UT-CS07): 100.0A（(10mV/A)/1000A(1V/A) ±(1.5%+5)
Frequency (Hz): 10Hz～1MHz ±(0.002%+5)
Resistance (Ω): 600.00Ω/6.0000kΩ/60.000kΩ/600.00kΩ/6.0000MΩ/60.00MΩ ±(0.07％+2）
Capacitance (F): 60.00nF/600.0nF/6.000μF/60.00μF/600.0μF/6.000mF/60.00mF ±(0.8％+3）
Temperature (℃): -40℃~1000℃ ±(1.0%+15)
Temperature (℉): -40℉~1832℉ ±(1.0%+30)
Duty Cycle (%): 10Hz～10kHz(10%~90%) ±(1.2%+5)
Features:
True RMS Value: √
Display count: 600000 (DCV); 9999 (frequency): √
Diode Test: 3.0V: √
Non-Contact Voltage: √
Continuity Buzzer: √
Data Hold (Manual/Auto): √
Peak Capture: √
Maximum/Minimum Value: √
High Voltage Alarm: √
Low Battery Indicator: √
Miswired Probe Alarm: √
Overrange Indicator: √
Auto Power Off: Around 15 minutes: √
Auto Backlight: √
Bluetooth Communication: √
Drop Test: 5m
IP Protection Level: IP67
Safety Standard Level: CAT IV 1000V
Certification: CE，cETLus，ROHS
General Characteristics:
Power supply: 1.5V AA * 2pcs
Product Color: Black + Red
Product Dimension: 220mm x 104mm x 67mm
Product weight: Around 835g (batteries included)
Accessories: Test lead, temperature probe, Clips, batteries.
