AC current (A): 1000A ±(2%+5)
DC current (A): 1000A ±(2%+5)
AC current frequency response: 40Hz~400Hz
Inrush current (A): 1000A ±(10%+10)
AC voltage (V):
+ 6V ±(1.2%+3)
+ 60V/600V/1000V: ±(1%+8)
DC voltage (V):
+ 600mV ±(0.8%+3)
+ 6V/60V ±(0.5%+5)
+ 600V ±(0.5%+5)
+ 1000V ±(0.5%+5)
Low pass filter (LPF ACV): 600V/1000V ±(2%+5)
AC voltage frequency response: 40Hz~400Hz
LoZ ACV: 600V/1000V ±(2%+5)
Resistance (Ω):
+ 600Ω ±(1%+3)
+ 6KΩ/60KΩ/600KΩ ±(1%+2)
+ 6MΩ/60MΩ ±(2%+8)
Capacitance (F):
+ 60nF ±(4%+25)
+ 600nF/6μF/60μF/600μF ±(4%+5)
+ 6mF/60mF ±(10%+9)
Low voltage frequency (Hz): 10Hz~1MHz ±(0.1%+3)
Duty cycle (%): 10%~90% ±(2.6%+7)
Power: 1.5V battery (R03) x 3
Display: 43mm x 45mm
Product color: Red and grey
Product net weight: 420g
Product size: 272mm x 81mm x 43.5mm
Standard accessories: Batteries, test leads
Features
Display count: 6000
Auto/Manual range: Yes
Jaw opening: 42mm
True RMS: Yes
Diode test: Yes
Continuity buzzer: Yes
NCV: Yes
MAX/MIN: Yes
Relative mode: Yes
VFC: Yes
Zero mode: Yes
Data hold: Yes
Auto power off: Yes
Flashlight: Yes
LCD backlight: Yes
Analog Bar: Yes
Input Impedance: ≥10MΩ
Category ratings: CAT IV 600V, CAT III 1000V
Drop test: 1m
CE certification: Yes
