- Withstand voltage
Output voltage （AC ）: Voltage range: 0.050kV—5.000kV
Voltage waveform: Sine wave
Distortion degree: < 3％
Operating Frequency: 50/60Hz
Frequency accuracy:±1%
Output power: 50VA（5.000kV 10mA）
Voltage regulation: ±(1.0%+50V) (Rated power）
Output voltage （DC ）: Voltage range: 0.050 kV—6.000kV
Signal source: 600Hz
Output power: 30VA（6.000kV 5mA）
Voltage regulation: ±（1.0% +100V) （Rated power）
Voltage resolution: 1V
Voltage output accuracy: ±(1.0%Set value+5V) (No load)
Voltage test accuracy: ±(1.0%Reading+5V)
- ARC Detector
Measuring range: AC: Off, level 1 ~ 9
DC: Off, level 1 ~ 9
- Comparator
Discrimination mode: Window comparison mode
Current lower limit ON: pass when I lower limit < Ix < I upper limit;
When Ix ≤ I lower limit or Ix ≥ I upper limit, fail. (I lower limit < I upper limit)
Current lower limit OFF: when Ix < I upper limit, pass; When Ix ≥ I upper limit, fail.
The discrimination method of insulation resistance is the same as above
Current upper limit setting: AC: 0.001mA – 10mA
DC: 0.1uA – 5mA
Current lower limit setting (LOWER OFF): AC: 0.001mA – 10mA
DC: 0.1uA –5mA
Resistance upper limit setting: OFF， 0.1MΩ - 10GΩ
Resistance lower limit setting: 0.1MΩ– 10GΩ
Discriminant output: PASS/FAIL LCD and LED display respectively and sound alarm
Interface & protocol: USB host、 HANDLER、 RS232C， Optional RS485， SCPI protocol
Upper computer software: Yes
Power: AC 110V/220V±10% 50~60Hz
Display mode: 4.3 inch LCD screen
Product size（W×H×D）: 295mm×117.6mm×465mm
Product net weight: 8.3kg
