UNI-T UT805A Bench Multimeter

DC voltage (V)(1000V): ±(0.015%+3)

AC voltage (V) (750V): ±(0.2%+100)

AC voltage (V) (10000V): -

DC current (A) (10A): ±(0.03%+10)

AC current (A)(10A): ±(0.3%+100)

Resistance (Ω):

+ 20MΩ : ±(0.02%+6)

+ 40MΩ: -

Capacitance (F):

+ 40mF: -

+ 6mF: ±(2%+5)

Frequency (Hz):

+ 10Hz~60MHz: ±(0.1%+3)

+ 40Hz~400MHz: -

Temperature:

+ -40°C~1000°C: -

+ -40°F~1832°F: -

Features

Display count Other Features: 200000

Duty ratio (0~100%): -

Auto power off/Low battery indication: No

Data storage: 100

USB interface/LCD backlight: Yes

Peak hold/Auto/manual alarm: No

Dot-matrix LCD 256 × 64 pixels: Yes

Analog bar graph: No

Input protection

General Characteristics

Power: UT805A: AC 220V/50Hz

Display: 128mm x 28mm

Product color: White and grey

Product net weight: UT805A: 3.2kg

Product size: UT805A: 300mm x 245mm x 105mm

Standard accessories: Test lead, multi-purpose socket, AC 220V power cord, software CD, RS-232 interface cable, USB interface cable, alligator clip, point contact temperature probe (UT804), probe (UT805A )

Standard individual packing: Carton box, English manual

Standard carton measurement: UT805A: 685mm x 450mm x 315mm

Standard carton gross weight: UT805A: 18kg
