Channels: 2
Bandwidth: 100MHz
Sampling rate: 1GS/s
Rise time: ＜3.5ns
Memory depth: 64kpts
Waveform capture rate: >5, 000wfms/s
Vertical scale (V/div): 1mV/div~20V/div
Time base scale (s/div): 2ns/div~50s/div
Timing accuracy: ≤±（50+2 × service life ）ppm
Time base mode: Y-T、X-Y、Roll
Storage methods: Setup, wave, bitmap
Trigger types: Edge, pulse width, alternate，Slope, video
Mathematical operations: ＋, －, ×, ÷, FFT
Auto measurements: Pk-Pk , Ampl, Max , Min, Low, Middle, High, Mean, RMS，OverSht,, PreSht, Period, Frequency、Rise, Fall, +Width，-Width, -Duty, +Duty,Delay,Phase，FRR,FRF,FFR,FFF,LRR,LRF,LFR,LFF,34 paramet ers in total
Displayed measurements: Display 5 measurements at the same time
Frequency counter: 6 bits
Interface: USB OTG,Pass/Fail
Power: 100-240VAC, 45-440Hz
Display: 7 inches TFT LCD, 800×480
Product color: White and grey
Product net weight: 3.5kg
Product size: 336mm×164mm×108mm
