UNI-T UTG4202A Function/Arbitrary Waveform Generator (200MHz; 2CH; 500MSa/s)

Max. frequency: 200MHz

Channels : 2

Sampling rate : 500MSa/s

Waveforms : Sine,square,ramp,harmonic,pulse,noise,DC voltage,arbitrary

Working modes : Continuous, modulation, sweep, burst

Modulation types : AM,FM,PM,ASK,FSK,PSK,BPSK,QPSK,OSK,PWM,SUM,QAM

Frequency Characteristics:

Sine : 1μHz~200MHz

Square/Pulse : 1μHz~60MHz

Ramp : 1μHz~5MHz

Harmonic : 1μHz~100MHz

Noise (-3dB) : 200MHz

Resolution : 1μHz

Arbitrary Waveform:

Frequency range: 1μHz~50MHz

Memory depth: 8pts~32Mpts

Vertical resolution : 16bits

Min rise/fall time (typical: 1Vpp) : <5ns

Power: 100V~240V AC, 50Hz/60Hz

Display: 8 inch TFT LCD, WVGA (800 x 480)

Product net weight: 3.5kg

Product size (W×H×D): 336mm x 164mm x 108mm
