Technical Data
IR resolution (Pixels):256×192
Field of view(FOV): 56°×42.2°
Thermal sensitivity(NETD): ≤50mK @25℃
Spatial resolution(IFOV): 3.8mrad
Frame rate: ≤25Hz
Focus: Focus free
Lens focal length: 3.2mm
Temperature measurement range: -20℃ ~ 550℃
Temperature scale: Low gain: -20℃~150℃
High gain: 0℃~550℃
Measurement modes: Industry, EST(Elevated Skin Temperature)
Accuracy: Industry: ±2° or ±2% whichever is greater (0℃~550℃) EST: ±0.5° (30℃~40℃)
Emissivity: 0.01~1.00 adjustable (0.95 default)
Functions
Color palettes: 7 (White hot, Lava, Ironbow,Black hot, Red hot, Rainbow, Rainbow HC)
Image modes: Thermal,Fusion,PIP
On screen analyzer: 3 Points/3 Lines/3 Rectangles
Hi/Lo temperature alarm: √
Video recording: √
General Characteristics
USB: Type-C
Drop proof: 1m
Image/Video storage format: JPEG, MP4
Certificates: CE,UKCA,FCC,RoHS
Languages: ZH, EN, FR, DE, IT, ES, SV
Product net weight: 12g
Product size: 33mm×28.2mm×11.3mm
Packing Details
Standard accessories: USB cable, English manual, Documents download operation guide card
Standard individual packing: Gift box
Standard Qty per carton: 20pcs
Standard carton size: 290mm×265mm×325mm
Standard carton G.W.: 4.4kg
